Hangzhou Zon Packaging Machinery Co.,Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | ZON PACK |
| Certification: | CE Certification |
| Model Number: | ZH-DM500 |
| Minimum Order Quantity: | 1 Set |
| Price: | 5500-5700USD per set |
| Packaging Details: | Wooden case |
| Delivery Time: | 20-25 Working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 199 Set per month |
| Name: | Food Grade Metal Detector | Model: | ZH-DM500 |
|---|---|---|---|
| Belt Speed: | 25m/min | Window Width: | 500mm |
| Belt Width: | 460mm | Frame Material: | SUS304 |
| Power Supply: | 220V/110V 50/60Hz | Alarm: | Stop Or Rejector |
| Rejector: | Air Blow, Pusher, Shifter | Max Weight: | 50kg |
| High Light: | 500mm Food Grade Metal Detectors,5Kg Food Grade Metal Detectors,500mm conveyor metal detector |
||
Automatic food inspection machine 500mm belt width belt conveyor food grade metal detector
Technical Feature
1. LCD DIsplay screen control panel with English and Chinese language
2. with the learning functions of automatic identification. Overcome the effect of products material efficiently.
3. Strong suppression for product effect of aquatic food products ,frozen foods & pickled foods strong anti-interference
& shock proof
4. Easily disassembly and conveniently clean
| Technical Specification | |||
| Model | ZH-DM | ||
| Type | 3008/3012/3015/3018 | 4008/4012/4015/4018 | 5015/5020/5025/5030 |
| Window Width | 300mm | 400mm | 500mm |
| Window Height | 80/120/150/180mm | 80/120/150/180mm | 200/250mm |
| Sensitivity for Fe | Φ0.7/0.7/0.7/0.8mm | Φ0.7/0.7/0.7/0.8mm | Φ0.8/1/1.2/1.5mm |
| Sensitivity for SS | Φ1.2/1.5/1.5/2.0mm | Φ1.2/1.5/1.5/2.0mm | Φ2.0/2.0/2.5/3.0mm |
| Belt Width | 280mm | 360mm | 460mm |
| Max Weight | 5Kg | 10kg | 50kg |
| Monitor | LCD | ||
| Belt Material | Food grade PVC, Options for PU and chain plate | ||
| Belt Speed | 25m/min | ||
| Alarm | Stop or rejector | ||
| Rejector | Air blow, Pusher, Shifter | ||
| Power Parameter | 220V/110V 50/60Hz | ||
| Protection Level | IP30/IP54/IP66 | ||
| Frame Material | SUS304 | ||
Application
The metal detector is widely used in Aquatic products,meat and poultry products,
preserved food,flour products,dried fruit,vegetables ,chemical materials and so on to ensure contaminated product
is detected.
