Hangzhou Zon Packaging Machinery Co.,Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | ZON PACK |
| Certification: | CE Certification |
| Model Number: | ZH-DW400 |
| Minimum Order Quantity: | 1 Set |
| Price: | 5000-6000USD per set |
| Packaging Details: | Wooden case |
| Delivery Time: | 20-25 Working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 300 Sets per month |
| Name: | High Speed Check Weigher | Model: | ZH-DW600 |
|---|---|---|---|
| Weighing Range: | 10-50kg | Frame Material: | SUS304 |
| Best Accuracy: | ±2g | Zero Calibration: | Auto Zero Tracking |
| Scale Interval: | 5g | Belt Speed: | 60m/min |
| Rejector: | Air Blow, Pusher, Shifter | Protection Level: | IP30/IP54/IP66 |
| Highlight: | High Speed Checkweigher Conveyor,IP66 High Speed Checkweigher,600mm belt checkweigher |
||
Engineer oversea support max speed 75pcs/min belt width 600mm high speed check weigher
Technical Feature
1. SIEMENS PLC and 7" touch screen, more stability and easier to operate;
2. Apply HBM load cell ensure high accuracy and stability (original from Germany);
3. Solid SUS304 structure ensure stable performance and precise weighing; Reject arm, air blast or
pneumatic pusher for selecting;
4. Belt disassembling without tools, which is easier to clean;
5. Install emergency switch at the size of machine, user friendly operation;
|
Technical Specification |
|||||||
| Model | ZH-DW160 | ZH-DW230S | ZH-DW230L | ZH-DW300 |
ZH-DW400 |
ZH-DW500 | ZH-DW600 |
| Weighing Range | 10-600g | 20-2000g | 20-2000g | 50-5000g | 0.2-10kg | 0.5-20kg | 10-50kg |
| Scale Interval | 0.05g | 0.1g | 0.1g | 0.2g | 1g | 1g | 5g |
| Best Accuracy | ±0.1g | ±0.2g | ±0.2g | ±0.5g | ±1g | ±2g | ±5g |
| Max Speed | 250 pcs/min | 200 pcs/min | 155pcs/min | 140pcs/min | 105pcs/min | 75pcs/min | 75pcs/min |
| Belt Speed | 70m/min | 70m/min | 70m/min | 70m/min | 70m/min | 60m/min | 60m/min |
| Product Size | 200mm (L) 150mm (W) |
250mm (L) 220mm (W |
350mm (L) 220mm (W) |
400mm (L) 290mm (W) |
550mm (L) 390mm (W) |
700mm (L) 490mm (W) |
1000mm (L) 590mm (W) |
| Weighing Platform Size |
280mm (L) 160mm (W) |
350mm (L) 230mm (W) |
450mm (L) 230mm (W) |
500mm (L) 300mm (W) |
650mm (L) 400mm (W) |
800mm (L) 500mm (W) |
1200mm (L) |
| No. of Sorting Segment | 2 Segments or 3 Segments | ||||||
| Rejector | air blow, Pusher, shifter | ||||||
| Power Parameter | 220V/110V 50/60Hz | ||||||
| Protection Level | IP30/IP54/IP66 | ||||||
| Frame Material | SUS304 | ||||||
Application
High accuracy checkweigher is suitable for testing the weight of a single product whether it is qualified or not, widely used
in electronics, pharmaceuticals, food, beverages, health products, cosmetic, light industry, agricultural and sideline products
and other industries. (Including soap, detergent etc.); oral products (including toothpaste, mouthwash, etc.); the other
(including cosmetics, skin care products, hair with cosmetics, Chemical products (including shoe polish, floor wax, deodorant,
insect repellent, etc.).
